CNC stone engraving machines are an excellent addition to any industry that deals with the production of stone carvings. With the use of CNC technology, these machines make stone carving a breeze. They can be used for producing intricate designs and patterns, engraving logos and text on stones, and for various other purposes.
One of the biggest advantages of CNC stone engraving machines is their ability to produce accurate and precise engravings. Because of their computer-controlled technology, they are able to create intricate and complex designs that would be difficult or impossible to achieve manually. This means that the end product is always of high quality and consistent.
In addition to being accurate and precise, CNC stone engraving machines are also extremely efficient. They can work on multiple stones simultaneously, which means that production is much faster than with manual machines. Furthermore, they require very little human intervention, which reduces the chance of human error and increases productivity.
CNC stone engraving machines are also highly customizable. This means that they can be programmed to produce different designs and patterns, depending on the needs of the user. They can also be used to engrave a wide variety of materials, including granite, marble, sandstone, and other types of natural stone.
Overall, CNC stone engraving machines are an excellent investment for any industry that deals with stone carvings. They are efficient, accurate, customizable, and produce high-quality work. With the use of this technology, stone carvings have become more accessible, faster to produce, and more precise.
Parameter Data:
| Processing Size | X: 1300mm Y: 1500mm Z: 350mm | ||||||
| Machine overall size | 2200mm*2500mm*2300mm | ||||||
| System | Weihong 60A | ||||||
| Spindle | 5.5KW *1 | ||||||
| Inverter | 5.5KW *1 | ||||||
| Motor | AC SERVO-Fully servo | ||||||
| Travelling rail | X/Y 30, Z 25 linear guide rail | ||||||
| Ball Screw System | 2505, TBI-Taiwan, Ball screw | ||||||
| Rack | Precision helical gear drive-Taiwan Brand | ||||||
| Cooling System | Water-cooling | ||||||
| Lubrication system | Automatic oil filling system | ||||||
| Lathe bed | Heavy-duty square tube welding bed, | ||||||
| stainless steel water tank, stainless cover | |||||||
| Spindle speed | 18000-24000 rpm | ||||||
| Machine Cablie | Chinese Shanghai Yichu | ||||||
| Control Switch | Schneider | ||||||
| Processing desk | The aluminum profile with PVC board | ||||||
| and customized t-shaped rod for stone carving | |||||||
| Dust protection | Fully enclosed | ||||||
| instruction | nc, eng, G-code,*u00,*mmg,*plt | ||||||
Single Head CNC Router – Precision 3D Engraving & Cutting Machine
A Single Head CNC Router is a computer‑controlled machining tool designed for high‑precision engraving, cutting, carving, milling, and shaping of stone, wood, MDF, acrylic, composites, aluminum, and other materials. Featuring a single working spindle, this CNC router is ideal for applications requiring detail‑oriented 2D and 3D work, making it a popular choice for stone fabrication workshops, furniture manufacturers, sign makers, and customized production environments.
Whether you're producing 3D carvings, detailed engravings, decorative elements, or high‑precision cutting tasks, a single head CNC router delivers sharp, repeatable, and automated machining performance.
Key Features & Advantages
🛠️ High‑Precision CNC Control
Equipped with advanced CNC motion control systems, the router offers precise cutting paths driven by digital files (DXF, PLT, BMP, NC, etc.) to guarantee exact shapes, consistent repeats, and complex geometries.
⚡ Industrial‑Grade Spindle
High power air‑cooled or water‑cooled spindle
Adjustable speed control for different materials
Stable performance with low vibration
The spindle's powerful rotation ensures smooth cutting on dense materials such as granite, marble, engineered stone, and hardwoods.
📐 Multi‑Axis Machining
Support for X/Y/Z axis movement allows:
2D vector cutting
3D engraving and profiling
Pocket machining
Hollowing and detailed carving
Accurate axis movement enables complex stone and wood designs without manual intervention.
💻 User‑Friendly Control Software
Comes with compatible software (e.g., NCStudio, Mach3, ArtCAM, Type3, Vectric Aspire) allowing:
Quick program import/export
Simulation and preview
Parametric adjustments for different materials
Offline programming and editing
🔩 Rigid Frame & Linear Guide
Heavy‑duty steel construction and high‑precision linear rails ensure machine stability, reduced vibration, and long‑lasting cutting accuracy.
Applications Across Industries
A Single Head CNC Router is highly versatile and widely used for:
🏛️ Stone & Marble Fabrication
3D relief engraving
Lettering and logos on stone
Edge profiling for countertops
Tombstone and memorial carving
🪵 Woodworking & Furniture
Cabinet panel carving
Decorative wood trim cutting
Custom furniture detail work
🪧 Signage & Advertising
3D text and logo engraving
Signboard cutting
Layered acrylic signage
🏭 Industrial & Prototype Machining
Aluminum and non‑ferrous metals (with proper tooling)
Composite panel shaping
Custom part production
🎨 Arts, Crafts & Custom Projects
Architectural ornamentation
Artistic sculpting
Customized gift and decor items
Technical Specifications (Typical / Customizable)
| Feature | Specification |
|---|---|
| Machine Type | Single Head CNC Router |
| Axis Travel (X/Y/Z) | Customizable (e.g., 1300×2500×200 mm) |
| Spindle Power | 3.0–9.0 kW (optional) |
| Spindle Speed | 0–24,000 RPM (adjustable) |
| Drive Type | Stepper / Servo motors |
| Control System | Mach3 / NCStudio / DSP |
| Guide Type | Linear rails / Rack & Pinion |
| Software Compatibility | ArtCAM, Type3, Vectric, AutoCAD |
| Working Table | Vacuum / T‑slot / Roller table |
| Power Supply | 220 V / 380 V (optional) |
| Cutting Materials | Stone, wood, MDF, acrylic, PVC, aluminum |
Customizations available based on cutting size needs, spindle power options, and automation upgrades.
Benefits of Using a Single Head CNC Router
✔ Precision & Repeatability
Automated CNC control produces identical cuts with micron‑level accuracy, eliminating manual error.
✔ High Production Efficiency
Ideal for batch production - one design can be repeated countless times with consistent results.
✔ Wide Material Compatibility
Supports a broad range of materials with the right tooling, from soft wood to hard stone.
✔ Cost‑Effective Fabrication
Reduces labor costs and machining time for detailed carving and complex profiles.
✔ Scalable & Customizable
Modular design allows upgrades such as dust collection, automatic tool changers (ATC), and rotary attachments for enhanced machining workflows.
Choosing the Right CNC Router for Your Shop
When selecting a Single Head CNC Router, consider:
🔍 Work Area Size
Match the table dimensions (X/Y/Z travel) to your typical workpiece size.
💡 Spindle Power
Higher spindle power (5–9 kW) is ideal for dense materials like granite and engineered stone, while lower power suits wood and acrylic.
⚙️ Control System
Choose a control platform and software that matches your design workflow (e.g., ArtCAM for 3D relief engraving).
🔌 Motor Drive
Servo motors provide higher speed and smoother acceleration than stepper systems for demanding jobs.
📦 Optional Features
Dust collection systems
Vacuum or T‑slot tables
Tooling kits and collets
Rotary attachments for cylindrical work
