Marble Wire Saw

Marble Wire Saw is a flexible superhard material cutting tool, and there are rubber type and spring type. Our product is of excellent quality, particularly sharp, and fast cutting speed. It has good adaptability and is suitable for the mining of marble quarries in all types of mines.

Marble Wire Saw has better functionality, deeper cutting depth, a very flat cutting surface, small saw seams, and no waste of resources. Our product is very safe and environmentally friendly. Using it for mining is noiseless and dust-free, and has a high degree of automation. The separated operation can effectively reduce the work intensity of workers and improve safety.



Marble cutting wire saw is an excellent tool that has revolutionized the marble industry. With this high-tech cutting system, it is now possible to cut marble blocks of any size, shape, or texture with great precision and accuracy.



Unlike traditional cutting methods where the blades can shatter or break, the flexible wire used in the wire saw is much safer. Additionally, the wire is often coated with a layer of diamond beads, which ensures that the wire stays sharp and durable throughout the cutting process.



The marble cutting wire saw is an excellent tool that has revolutionized the marble industry. It is cost-effective, highly efficient, produces clean and precise cuts, and is safe to use. Whether you are a professional sculptor or a large factory owner, the wire saw can help you cut marble blocks with unparalleled ease and precision.





Technical Data

Specification	11/11.5	11/11.5	11/11.5	11/11.5	11/11.5	11/11.5	11/11.5	11/11.5	11/11.5
Fixed by	Spring	Spring	Spring	Rubber	Rubber	Rubber	Rubber+Spring	Rubber+Spring	Rubber+Spring
Beads No./m	28-33	28-33	28-33	37/40	37/40	37/40	37/40	37/40	37/40
Cutting material	Soft Marble	Medium Hard Marble	Ultrahard Marble	Soft Marble	Medium Hard Marble	Ultrahard Marble	Soft Marble	Medium Hard Marble	Ultrahard Marble
Cutting speed	10-25	8-16	5-10	10-25	8-16	5-10	10-18	8-16	5-10
Wire life	30-55	15-35	15-25	30-55	15-35	15-25	30-55	15-35	15-25
Line speed	30-38	30-35	28-35	35-40	33-40	28-35	35-40	33-40	28-35



Note

Different stone is varied in characteristic, for more details, please feel free to contact us.





Marble Wire Saw – High-Precision Diamond Wire for Marble Quarrying & Block Cutting

The Marble Wire Saw is a high-performance diamond wire engineered for marble block extraction, quarrying, and slab production. Made from a high-strength steel cable embedded with industrial diamonds, it delivers clean, precise cuts with minimal kerf width and low material waste.

Ideal for marble quarries, stone processing plants, and construction projects, it allows vertical, horizontal, inclined, and blind cuts, providing maximum flexibility and efficiency compared to traditional frame saws or blasting methods.



---

Key Features & Advantages

✔ High-Strength Steel Core

Multi-strand steel cable ensures flexibility, tensile strength, and resistance to breakage.

Supports continuous, heavy-duty cutting in marble quarries and fabrication plants.

✔ Premium Industrial Diamond Beads

Sintered or electroplated diamond beads are embedded along the wire at regular intervals.

Provides fast, smooth cutting, producing high-quality blocks with minimal surface damage.

✔ Optimized for Marble Material

Specifically designed for soft to hard marble varieties.

Produces flat surfaces, narrow kerfs, and minimal stone loss, increasing usable stone yield.

✔ Flexible & Durable Design

Rubber, spring, or combined coatings reduce vibration, improve wire flexibility, and extend service life.

Suitable for both wet and dry cutting, depending on quarry conditions.

✔ Environmentally Friendly & Safe

Low dust, low noise, and minimal vibration compared to traditional blasting or mechanical cutting.

Safer for quarry workers and reduces the need for secondary finishing.

✔ High Cutting Speed & Efficiency

Wire can operate at 20–40 m/s, improving daily productivity.

Narrow kerf reduces cutting time and labor costs.



---

Typical Applications

Marble Quarrying & Block Extraction – Cutting large marble blocks efficiently and precisely.

Slab Production & Stone Processing – Preparing slabs for polishing, finishing, or architectural use.

Architectural Stone Projects – Creating accurate cuts for decorative elements.

Complex Quarry Layouts – Supports vertical, inclined, and horizontal cuts with high precision.

Industrial & Construction Cutting – Cutting marble walls, columns, and structural stone elements.



---

How Marble Wire Saw Works

Drill guide holes in the stone block.

Thread the diamond wire through these holes to form a continuous loop.

Tension the wire and rotate it using a diamond wire saw machine.

Apply water or coolant for dust control and bead cooling.

Diamond beads grind the marble to create precise, smooth cuts.

This method produces high-quality blocks with minimal surface cracking and ensures consistent results across large quarries.



---

Technical Specifications & Selection Guide

Wire Diameter: Typically 10.5 mm – 11.5 mm.

Bead Count: 28–40 beads per meter, depending on marble hardness.

Wire Type: Spring, rubber, or combined coatings.

Cutting Speed: 30–40 m/s recommended.

Wire Life: 15–55 m² per wire depending on bead type and stone hardness.

Selection Tips:

Harder marble requires closer bead spacing and robust coatings.

Softer marble benefits from lower bead density and thinner wires.

Choose the coating type (rubber, spring, or plastic) based on flexibility and vibration damping needs.

Ensure compatibility with your wire saw machine regarding tension, RPM, and pulley system.



---

Advantages Over Traditional Marble Cutting Methods

Higher Yield: Minimal kerf reduces material waste.

Better Block Quality: Smooth surfaces with fewer fractures.

Multi-Directional Cutting: Vertical, horizontal, inclined, or blind cuts possible.

Reduced Dust & Noise: Safer and cleaner quarry environment.

Lower Labor Costs: Faster cutting reduces manpower and finishing requirements.



Features of Marble Wire Saw







Marble Wire Saw Packing and Delivery

Marble Wire Saw if small quantity pack in paper box, if large quantity, they are packed in polywood case before delivery. And delivery by express or by air, normally pack in small paper box, while delivering by sea, normally pack in polywood case.
