Pneumatic Rock Drill Machine

Pneumatic Rock Drill Machine is an impact drilling machine that powered by compressed air.

Send Inquiry

Description

Pneumatic Rock Drill Machine is an impact drilling machine that powered by compressed air. It can drill horizontally or vertically, and usually in cleavable rocks such as granite. It is an automatic product that can effectively reduce labor and is very convenient to use.

It is mainly used for block separating, and divides the big block into small blocks, making full use of the compressed air to drive the driller drilling holes. It is popular in western countries, because it is automatically and requires less labour.

Technical Data

Hole Diameter	Dia-34mm - Dia-42mm
Drill depth	Max.6m
Single rod drill speed	5-20m/h
Single advance	2m
Air consumption	10-12m3/min
Air pressure	0.5-0.7Mpa
Track travel	1x4m
Advance power	1.5KW
Total weight	1000KG

Pneumatic Rock Drill Machine Details

Product Details

Application: in cleavability rocks like granite quarry and etc.

Original: Quanzhou, China

Certification: ISO9001,CE, SGS and etc.

Price: Negotiable

Material: steel and Pneumatic drive

Voltage: 380V 50Hz, the voltage can be as local demand

Payment term: TT, LC

Delivery date: Negotiable

Packing: export standard

Market: Southeast Asia/Middle East/ Africa/South America/Europe/North America

Warranty: 1 year

MOQ: 1 set

Features

FEATURE 01

Multi-functional, can be working in vertical or horizontal drilling

FEATURE 02

Chain wheel applied to put forward drilling automatically by a chain, highly increased the lifting speed

FEATURE 03

The special wedges are good for installation and fastening

FEATURE 04

Different specifications of button bit, cross bit, or flat bit can be fitted

FEATURE 05

Piezometer is equipped in lubrication system to make sure the rock driller working safely and reliably

FEATURE 06

Applied to lift support in the base to meet the needs of different working conditions

Advantages

Heavy rock drill hammer is driven by compressed air, which highly increased the efficiency

Automatically moving lengthways or transverse, highly reduced the working intensity

Unique lubrication system make sure the rock driller working steadily and smoothly.

After-sales service

Exclude damage to machine parts caused by intentional damage or operational errors. Consumables can be replaced free of charge during the warranty period.

Application

Pneumatic Rock Drill Machine
